Examples of AS 3745-compliant evacuation diagrams across residential and commercial property types. Each diagram is tailored to one You Are Here location and includes every AS 3745 required element.
These are real AS 3745 diagrams by EvacPath, from A$70 per diagram. You see your first draft before you pay.
Section 01
Portfolio
Elements visible on every diagram
You Are Here star marker
Primary exit paths (solid green arrows)
Alternative exit paths (dashed green arrows)
Fire extinguisher and first aid locations
Assembly area
RACE procedure panel
North arrow and site plan
Legend, address, and title block
Note
Sample diagrams shown use fictional addresses and have been sanitized for privacy. Your diagrams include your actual site address, equipment locations, and layout specific to your building.
